Alpha Wire offers 50-, 75-, 93-, and 100-ohm coaxial, twinaxial, and triaxial cables in a wide range of insulation and jacket materials and rated for UL, CSA and military specifications.
We now also provide non-magnetic coaxial cable options 9849 and 9851, which provide better signal transmission with minimal distortion while handling higher frequencies.
Looking for a space-saving option? We also offer Micro Coaxial cable, ideal for customers looking for uninterrupted signal transmission in compact spaces.
| Diameter ("in") | ||||||||||||||
| 1) Component 1 | 1 x 1 COAX | |||||||||||||
| a) Conductor | 48 (7/56) AWG Silver Copper Alloy | 0.0015 | ||||||||||||
| b) Insulation | 0.0011" Wall, Nom. PFA | 0.0037 | ||||||||||||
| (1) Color(s) | ||||||||||||||
|
||||||||||||||
| 2) Shield | Silver Platted Copper Alloy SPIRAL Shield, 90% Coverage, min. | |||||||||||||
| 3) Jacket | 0.0009" Wall, Nom., PFA | 0.0068 | ||||||||||||
| a) Color(s) | WHITE | |||||||||||||
| 1) CE | EU Low Voltage Directive 2006/95/EC | |
| 1) CE: EU Directive 2011/65/EU(RoHS2) | ||
| This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011. No exemptions are required for RoHS Compliance on this item. Refer to the RoHS Certificate of Compliance for more detail. | ||
| 2) REACH Regulation (EC 1907/2006) | ||
| This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration. | ||
| Physical & Mechanical Properties | |
|---|---|
| 1) Temperature Range | -70 to 200°C |
| 2) Bend Radius | 10X Cable Diameter |
| Electrical Properties | Engineering purposes only |
| 1) Voltage Rating | 30 VRMS |
| 2) Characteristic Impedance | 50 Ω +/- 5 |
| 3) Ground Capacitance | 36.6 pF/ft @1 kHz, Nominal |
| 4) Velocity of Propagation | 69 % |
| 5) Conductor DCR | 7010.4 Ω/1000ft @20°C, max. |
| 6) Attenuation (max. dB/100ft.) | 61 @ 10 MHz |
| Packaging | Flange x Traverse x Barrel (inches) |
| a) 328 FT | 5.12 x 3.54 x 2.36 Continuous Length |
| Spool dimensions may vary slightly. |
