Wind Turbines

Renewable power from the wind, reliable cables from Alpha Wire

Alpha Wire offers cables with an unmatched combination of performance, reliability, and quality to keep turbines delivering energy day in and day out.

Xtra-Guard® 4  performance cable withstands the temperature extremes of the wind turbine environment. Its durable construction offers three times the low-temperature flexibility of ordinary PVC, provides good resistance to oils, solvents, chemicals, and fuels, and is approved for wind turbine tray cable (WTTC) applications.

Xtra-Guard Flex Torsion  cable withstands continuous flexing, including multiaxis torsional movements, making it an excellent choice for wind vanes and anemometers that experience random movement.

Xtra-Guard Flex Motor Supply   cable combines excellent flexibility in a tough abrasion and oil-resistant design with a diameter smaller than most comparable motor supply cables—making it well suited for the tight spaces in wind turbines for connecting AC drives, servo drives, and variable-frequency drives. cable combines excellent flexibility in a tough abrasion and oil-resistant design with a diameter smaller than most comparable motor supply cables—making it well suited for the tight spaces in wind turbines for connecting AC drives, servo drives, and variable-frequency drives.

Series M  flexible control cables are used for stationary/cable tray and for light to moderate flexing applications. With MTW and WTTC approvals, Series M cables offer excellent resistance to oil, chemicals, and sunlight.flexible control cables are used for stationary/cable tray and for light to moderate flexing applications. With MTW and WTTC approvals, Series M cables offer excellent resistance to oil, chemicals, and sunlight.flexible control cables are used for stationary/cable tray and for light to moderate flexing applications. With MTW and WTTC approvals, Series M cables offer excellent resistance to oil, chemicals, and sunlight.flexible control cables are used for stationary/cable tray and for light to moderate flexing applications. With MTW and WTTC approvals, Series M cables offer excellent resistance to oil, chemicals, and sunlight.

Instrumentation  cables are available in a wide range of configurations for monitoring and telemetry needs.










Xtra-Guard

4 Cable











Xtra-Guard High-Flex Torsion Cable









Motor Supply Cable











Series M  Flexible Control Cable




















Instrumentation

Cable









Temperature Range









-50°C to 125°C









-30 to +80









25°C to +90°C









-25°C to +90°C

















-20°C to +105°C (PLTC) -20°C to +90°C (TC)









Voltage Rating









600/300









600









600









600

















600/300









Conductor Range









24 – 14 AWG









24 – 10 AWG









16 – 6 AWG









18 – 8 AWG



















22 – 12 AWG









No. of Conductors









2 – 40 mulitconductor 1 – 27 pairs









3 – 7









4









3 – 65

















1 – 35 pairs 1 – 8 triads









UL









AWM Style20238 TC-ER (600 V) PLTC (300 V)









AWM 20234 MTW









TC-ER (600 V) MTW









TC-ER (600 V) MTW PLTC (300 V)

















PLTC (300 V) TC (600 V)









WTTC Approval









Yes









Yes









Yes









Yes



































AWM I/II A/B FT-1









AWM I/II A/B FT-1









AWM I/II A/B FT-4









AWM I/II A/B



















CMG FT4









ShieldingOptions









Unshielded Foil shield Supra-Shield foil/ braid shield









Unshielded Braid shield









Foil/braid shield









Unshielded

















Unshielded Foil shield Foil/braid shield









Oil Resistant









Good









Excellent









Good









Good



























UV Resistant









Excellent









Excellent









Excellent









Excellent

















Excellent









Motor Size*









FHP to 12 hp









FHP to 20 hp









10 to 40 hp































Motor sizes are approximate and are based on 460V, 3 phase motors. Consult NEC Article 430 for sizing requirements.
