Xtra-Guard® 4

Xtra-Guard® 4 - Extreme temperature capability handles hot, cold, spills High TemperatureLow TemperatureUltraviolet LightEMI Noise

  • Extended-temperature cable with a temperature range from -50°C to +125°C
  • Features a high-performance TPE insulation and jacket offering three times the low-temperature flexibility of ordinary PVC
  • Moderate resistance to oils, solvents, chemicals, and fuels
  • Outstanding ultraviolet light stability in all jacket colors
  • UL Rated TC 600 V and PLTC 300 V for cable tray applications (except 24 AWG)
  • Pennsylvania Bureau Deep Mining Safety approved for mine-wide monitoring systems
  • Provides exceptional protection against EMI interference when Supra-Shield is specified

Xtra-Guard Performance Cable Brochure

Multiconductor Cable Conductor Color Codes

Multipair Cable Conductor Color Codes

Need a more unique construction? Request a Custom Cable Design

Filter Products By:











Select Products Below To:

1 to 20 of 286 Items | | Previous Next
Select All
Add Selected to My CatalogAdd Selected to My Catalog Add Selected to Sample Request Form Add Selected to Sample Request Form Email
(Ctrl+Click if PDF doesn't appear)
  Part # Type Shielding Voltage AWG # of Elements Jacket Diameter Applicable Specifications
45002 Conductor  UNSHIELDED  300  22  0.218  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
45003 Conductor  UNSHIELDED  300  22  0.228  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
45004 Conductor  UNSHIELDED  300  22  0.244  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
45006 Conductor  UNSHIELDED  300  22  0.281  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
45008 Conductor  UNSHIELDED  300  22  0.301  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
45010 Conductor  UNSHIELDED  300  22  10  0.342  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
45010/15 Conductor  UNSHIELDED  300  22  15  0.38  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
45010/20 Conductor  UNSHIELDED  300  22  20  0.441  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
45010/25 Conductor  UNSHIELDED  300  22  25  0.486  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
45012 Conductor  UNSHIELDED  300  24  0.2  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237
45013 Conductor  UNSHIELDED  300  24  0.209  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237
45014 Conductor  UNSHIELDED  300  24  0.224  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237
45016 Conductor  UNSHIELDED  300  24  0.257  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237
45018 Conductor  UNSHIELDED  300  24  0.275  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237
45020 Conductor  UNSHIELDED  300  24  10  0.312  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237
45020/15 Conductor  UNSHIELDED  300  24  15  0.347  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237
45020/20 Conductor  UNSHIELDED  300  24  20  0.383  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237
45020/25 Conductor  UNSHIELDED  300  24  25  0.424  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237
45031 Pair  UNSHIELDED  300  18  0.252  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
45032 Pair  UNSHIELDED  300  18  0.353  CA Prop 65, CE, CSA AWM I/II A/B, CSA FT1, Pennsylvania Bureau of Mine Safety Approved, UL AWM 20237, UL PLTC
