Part # Construction Type  RG Type  Impedance  Shielding  AWG  Stranding  Core Diameter  Jacket Diameter  Applicable Specifications
9817 COAX  Twinax  100  BRAID  20  7/28  0.236  0.33  UL AWM 2498
(Ctrl+Click if PDF doesn't appear)
 Diameters (In)
1) Component 1 1 X 2 COAX
a) Conductor 20 (7/28) AWG (1/C TC - 1/C BC) 0.037
b) Insulation 0.023" Wall, Nom. Polyethylene(PE) 0.083
(1) Color(s)
Cond Color Cond Color Cond Color
1 CLEAR 2 CLEAR
c) Cabling 2 COAX Cabled
(1) Twists: 4.0 Twists/foot (min)
d) Jacket 0.035" Wall, Nom.,Polyethylene (PE)0.236+/- 0.004
(1) Color(s) CLEAR
2) Shield TC BRAID Shield,85% Coverage, Min.
3) Jacket 0.033" Wall, Nom.,PVC0.330+/- 0.010
a) Color(s) BLACK
b) Print ALPHA WIRE-* P/N 9817
RU AWM STYLE 2498 CE ROHS
* = Factory Code
1) UL AWM/STYLE 2498 80°C / 300 VRMS
2) CE:EU Low Voltage Directive 2006/95/EC
1) CE: EU Directive 2011/65/EU(RoHS2), EU Directive 2015/863/EU (RoHS3):
 This product complies with European Directive 2011/65/EU (RoHS Directive) of the European Parliament and of the Council of 8 June 2011 and the amending Directive 2015/863/EU of 4 June 2015 . No Exemptions are required for RoHS Compliance on this item. Consult Alpha Wire's web site for RoHS C of C.
2) REACH Regulation (EC 1907/2006):
 This product does not contain Substances of Very High Concern (SVHC) listed on the European Union's REACH candidate list in excess of 0.1% mass of the item. For up-to-date information, please see Alpha's REACH SVHC Declaration.
3) California Proposition 65:Exempt from warning labels based on the Consent Judgment. Please see Alpha's CA Prop 65 Statement for more information.
Physical & Mechanical Properties
1) Temperature Range-20 to 80°C
2) Bend Radius 10X Cable Diameter
3) Pull Tension 25 Lbs, Maximum
Electrical Properties(For Engineering purposes only)
1) Voltage Rating 300 VRMS
2) Characteristic Impedance 100 Ω
3) Inductance 0.155 µH/ft, Nominal
4) Mutual Capacitance 14.5 pf/ft @1 kHz, Nominal
5) Ground Capacitance 23 pf/ft @1 kHz, Nominal
6) Velocity of Propagation 66 %
7) Conductor DCR 9.5 Ω/1000ft @20°C, Nominal
8) OA Shield DCR 3 Ω/1000ft @20°C, Nominal
9) Attenuation, Nom dB/100ft 0.4 @ 1 MHz
  1.2 @ 10 MHz
  2.5 @ 50 MHz
  4.1 @ 100 MHz
  6.4 @ 200 MHz
  10.2 @ 400 MHz
PackagingFlange x Traverse x Barrel (inches)
a) 1000 FT 18 x 12 x 8 Continuous length
b) 500 FT 12 x 12 x 3.5 Continuous length
c) 100 FT 12 x 4.5 x 3.5 Continuous length
 [Spool dimensions may vary slightly]
