Xtra-Guard® 3

Xtra-Guard® 3 - Direct burial—no conduit needed Ultraviolet LightOil, Chemicals, Solvents, FuelsDirect BurialEMI Noise

  • The preferred outdoor cable for direct burial
  • 6 times the water resistance of PVC
  • Features a specially formulated polyethylene jacket for outstanding service life and ultraviolet light stability in all jacket colors
  • Resistant to the effects of weathering, moisture, and UV aging without the costly use of conduit
  • Supra-Shield® provides exceptional protection against conducted or electrical noise in high- and low- frequency environments where EMI interference is pervasive

Xtra-Guard Performance Cable Brochure

Multiconductor Cable Conductor Color Codes

Multipair Cable Conductor Color Codes

Filter Products By:




1 to 20 of 140 Items | | Previous Next
  • Download Pdf
  Part # Type Shielding Voltage AWG # of Elements Jacket Diameter Applicable Specifications
35002 Conductor  UNSHIELDED  300  22  2  0.167  CA Prop 65, UL AWM 10002
35003 Conductor  UNSHIELDED  300  22  3  0.175  CA Prop 65, UL AWM 10002
35004 Conductor  UNSHIELDED  300  22  4  0.188  CA Prop 65, UL AWM 10002
35006 Conductor  UNSHIELDED  300  22  6  0.218  CA Prop 65, UL AWM 10002
35008 Conductor  UNSHIELDED  300  22  8  0.233  CA Prop 65, UL AWM 10002
35010 Conductor  UNSHIELDED  300  22  10  0.267  CA Prop 65, UL AWM 10002
35010/15 Conductor  UNSHIELDED  300  22  15  0.297  CA Prop 65, UL AWM 10002
35052 Conductor  UNSHIELDED  300  20  2  0.207  CA Prop 65, UL AWM 1569
35053 Conductor  UNSHIELDED  300  20  3  0.218  CA Prop 65, UL AWM 1569
35054 Conductor  UNSHIELDED  300  20  4  0.236  CA Prop 65, UL AWM 1569
35056 Conductor  UNSHIELDED  300  20  6  0.278  CA Prop 65, UL AWM 1569
35058 Conductor  UNSHIELDED  300  20  8  0.3  CA Prop 65, UL AWM 1569
35060 Conductor  UNSHIELDED  300  20  10  0.347  CA Prop 65, UL AWM 1569
35060/15 Conductor  UNSHIELDED  300  20  15  0.389  CA Prop 65, UL AWM 1569
35062 Conductor  UNSHIELDED  300  18  2  0.225  CA Prop 65, UL AWM 1569
35063 Conductor  UNSHIELDED  300  18  3  0.237  CA Prop 65, UL AWM 1569
35064 Conductor  UNSHIELDED  300  18  4  0.258  CA Prop 65, UL AWM 1569
35066 Conductor  UNSHIELDED  300  18  6  0.305  CA Prop 65, UL AWM 1569
35068 Conductor  UNSHIELDED  300  18  8  0.33  CA Prop 65, UL AWM 1569
35070 Conductor  UNSHIELDED  300  18  10  0.383  CA Prop 65, UL AWM 1569
